In this tutorial, we design an end-to-end evaluation workflow for PerceptionBench. This multimodal benchmark measures fine-grained visual perception capabilities across tasks such as OCR, counting, localization, contextual reasoning, comparison, depth understanding, and hallucination detection. We begin by configuring a Colab-compatible environment, installing the required libraries, and loading a balanced subset of the dataset through a robust multi-stage streaming and download strategy. We then decode base64-encoded images, parse interleaved image placeholders, normalize each example into a consistent record format, and analyze the dataset’s capability distribution, image requirements, answer types, and source benchmarks. From there, we construct a unified evaluation harness that supports a blind-prior baseline, OpenAI-compatible multimodal APIs, and local Hugging Face vision-language models. We also implement rule-based and optional LLM-assisted judging, calculate bootstrap confidence intervals, examine performance across difficulty slices, compare capability profiles with the included leaderboard, and export reproducible prediction and reporting artifacts.
Copy CodeCopiedUse a different Browserimport os, sys, io, re, json, time, math, base64, random, hashlib, subprocess, warnings
from collections import Counter, defaultdict
from concurrent.futures import ThreadPoolExecutor, as_completed
warnings.filterwarnings(“ignore”)
CFG = dict(
REPO = “moonshotai/PerceptionBench”,
SPLIT = “train”,
N_PER_CATEGORY = 12,
MAX_SCAN = 1200,
SEED = 0,
LOAD_MODE = “stream”,
BACKEND = “blind”,
API_BASE = os.environ.get(“PB_API_BASE”, “https://api.openai.com/v1”),
API_KEY = os.environ.get(“PB_API_KEY”, “”),
API_MODEL = os.environ.get(“PB_API_MODEL”, “gpt-4o-mini”),
API_WORKERS = 4,
API_MAX_TOKENS = 512,
LOCAL_MODEL = “HuggingFaceTB/SmolVLM2-2.2B-Instruct”,
LOCAL_MAX_NEW = 128,
MAX_IMAGE_SIDE = 1024,
JPEG_QUALITY = 90,
JUDGE = “rule”,
NUM_REL_TOL = 0.0,
OUT_DIR = “/content/perceptionbench_out” if os.path.isdir(“/content”) else “./perceptionbench_out”,
INSTALL_DEPS = True,
SHOW_PLOTS = True,
)
random.seed(CFG[“SEED”])
os.makedirs(CFG[“OUT_DIR”], exist_ok=True)
def _sh(pkgs):
subprocess.run([sys.executable, “-m”, “pip”, “install”, “-q”, *pkgs],
check=False, stdout=subprocess.DEVNULL, stderr=subprocess.DEVNULL)
if CFG[“INSTALL_DEPS”]:
print(“[setup] installing dependencies (quiet, ~30s on a cold Colab)…”)
_sh([“datasets>=3.0.0”, “huggingface_hub>=0.25.0”, “pillow”, “pandas”,
“numpy”, “matplotlib”, “requests”, “pyarrow”])
if CFG[“BACKEND”] == “local”:
_sh([“transformers>=4.51.0”, “accelerate”, “torch”, “num2words”])
import numpy as np
import pandas as pd
import requests
import matplotlib
import matplotlib.pyplot as plt
from PIL import Image
matplotlib.rcParams.update({“figure.dpi”: 110, “font.size”: 9, “axes.grid”: True,
“grid.alpha”: .25, “axes.spines.top”: False,
“axes.spines.right”: False})
print(“[setup] readyn”)
We configure the PerceptionBench environment, define the dataset, backend, image-processing, judging, and output settings, and initialize reproducible random behavior. We install the required libraries for dataset loading, numerical analysis, visualization, HTTP communication, and image processing. We also configure Matplotlib and prepare the output directory so the remaining evaluation workflow runs consistently in Google Colab or a local environment.
Copy CodeCopiedUse a different Browserdef _iter_rows(repo, split, mode, max_scan):
“””Yield dict rows, trying progressively heavier strategies.”””
from datasets import load_dataset
if mode == “full”:
print(“[load] full download (~1.63 GB) …”)
ds = load_dataset(repo, split=split)
for i, r in enumerate(ds):
if i >= max_scan:
return
yield r
return
try:
from huggingface_hub import HfApi, hf_hub_url
api = HfApi()
files = api.list_repo_files(repo, repo_type=”dataset”, revision=”refs/convert/parquet”)
pq = sorted(f for f in files if f.endswith(“.parquet”) and f”/{split}/” in f)
if pq:
urls = [hf_hub_url(repo, f, repo_type=”dataset”, revision=”refs/convert/parquet”) for f in pq]
print(f”[load] streaming {len(urls)} parquet shard(s) from refs/convert/parquet”)
ds = load_dataset(“parquet”, data_files=urls, split=”train”, streaming=True)
for i, r in enumerate(ds):
if i >= max_scan:
return
yield r
return
except Exception as e:
print(f”[load] parquet stream unavailable ({type(e).__name__}: {e}); falling back”)
try:
print(“[load] streaming original data files”)
ds = load_dataset(repo, split=split, streaming=True)
for i, r in enumerate(ds):
if i >= max_scan:
return
yield r
return
except Exception as e:
print(f”[load] json stream failed ({type(e).__name__}); doing a full download”)
ds = load_dataset(repo, split=split)
for i, r in enumerate(ds):
if i >= max_scan:
return
yield r
def stratified_subset(repo, split, n_per_cat, max_scan, mode):
“””Balanced sample across `error_category` — the ten atomic capabilities.
Balancing matters: the benchmark reports a *capability profile*, and an
unbalanced sample makes the overall number a weighted average of whichever
capabilities happened to appear first in the shard.
“””
buckets, scanned, t0 = defaultdict(list), 0, time.time()
for row in _iter_rows(repo, split, mode, max_scan):
scanned += 1
cat = row.get(“error_category”) or “unknown”
if len(buckets[cat]) < n_per_cat:
buckets[cat].append(row)
if scanned % 100 == 0:
filled = sum(len(v) >= n_per_cat for v in buckets.values())
print(f” scanned={scanned:5d} categories={len(buckets):2d} ”
f”filled={filled:2d} {time.time()-t0:5.1f}s”, end=”r”)
if scanned >= 250 and len(buckets) >= 10 and all(len(v) >= n_per_cat for v in buckets.values()):
break
rows = [r for v in buckets.values() for r in v]
random.Random(CFG[“SEED”]).shuffle(rows)
print(f”n[load] scanned {scanned} rows -> kept {len(rows)} across ”
f”{len(buckets)} capabilities ({time.time()-t0:.1f}s)”)
return rows, scanned
ROWS, N_SCANNED = stratified_subset(
CFG[“REPO”], CFG[“SPLIT”], CFG[“N_PER_CATEGORY”], CFG[“MAX_SCAN”], CFG[“LOAD_MODE”])
We implement a resilient dataset loader that first attempts converted Parquet streaming, then falls back to streaming the original files, and finally performs a full download when necessary. We scan the dataset while limiting the number of processed rows and organize examples into capability-specific buckets using the error_category field. We then create a balanced, shuffled subset so each visual capability contributes a comparable number of evaluation questions.
Copy CodeCopiedUse a different BrowserDATA_URI_RE = re.compile(r”^data:(image/[A-Za-z0-9.+-]+);base64,(.*)$”, re.S)
PLACEHOLDER_RE = re.compile(r”<|image[ _](d+)|>”)
def decode_image(entry):
“””data-URI string | raw b64 | bytes | HF Image dict -> PIL.Image (RGB).”””
if isinstance(entry, Image.Image):
return entry.convert(“RGB”)
if isinstance(entry, dict):
if entry.get(“bytes”):
return Image.open(io.BytesIO(entry[“bytes”])).convert(“RGB”)
if entry.get(“path”):
return Image.open(entry[“path”]).convert(“RGB”)
if isinstance(entry, (bytes, bytearray)):
return Image.open(io.BytesIO(entry)).convert(“RGB”)
s = str(entry).strip()
m = DATA_URI_RE.match(s)
b64 = m.group(2) if m else s
b64 = re.sub(r”s+”, “”, b64)
b64 += “=” * (-len(b64) % 4)
return Image.open(io.BytesIO(base64.b64decode(b64))).convert(“RGB”)
def load_images(row):
imgs = row.get(“image”) or []
if isinstance(imgs, (str, bytes, dict)):
imgs = [imgs]
out = []
for e in imgs:
try:
out.append(decode_image(e))
except Exception as err:
print(f” [warn] undecodable image on idx={row.get(‘index’)}: {err}”)
return out
def shrink(img, max_side, quality):
“””Downscale + re-encode. Returns (PIL, data_uri). Controls the token bill:
a 3000px screenshot can cost >2k vision tokens per image, and these
questions carry up to 8 images each.”””
w, h = img.size
if max(w, h) > max_side:
s = max_side / max(w, h)
img = img.resize((max(1, int(w * s)), max(1, int(h * s))), Image.LANCZOS)
buf = io.BytesIO()
img.save(buf, format=”JPEG”, quality=quality)
return img, uri
def split_on_placeholders(problem, n_images):
“””`<|image_1|>text<|image_2|>?` -> [(‘image’,0),(‘text’,’…’),(‘image’,1)…]
Any image never referenced by a placeholder is appended at the end, so we
never silently drop visual evidence.”””
parts, last = [], 0
for m in PLACEHOLDER_RE.finditer(problem):
chunk = problem[last:m.start()].strip()
if chunk:
parts.append((“text”, chunk))
i = int(m.group(1)) – 1
if 0 <= i < n_images:
parts.append((“image”, i))
last = m.end()
tail = problem[last:].strip()
if tail:
parts.append((“text”, tail))
used = {p[1] for p in parts if p[0] == “image”}
for i in range(n_images):
if i not in used:
parts.append((“image”, i))
return parts
def to_record(row):
imgs = load_images(row)
problem = (row.get(“problem”) or “”).strip()
return dict(
index = row.get(“index”),
problem = problem,
answer = str(row.get(“answer”, “”)).strip(),
hint = (row.get(“hint”) or “”).strip(),
category = row.get(“error_category”) or “unknown”,
source_bmk = row.get(“source_bmk”) or “NA”,
source_idx = row.get(“source_idx”),
images = imgs,
n_images = len(imgs),
n_placeholders= len(PLACEHOLDER_RE.findall(problem)),
q_chars = len(problem),
px_total = sum(w * h for w, h in (im.size for im in imgs)),
max_side = max([max(im.size) for im in imgs], default=0),
)
print(“[decode] decoding images…”)
RECORDS = [to_record(r) for r in ROWS]
RECORDS = [r for r in RECORDS if r[“images”] and r[“answer”]]
print(f”[decode] {len(RECORDS)} usable recordsn”)
def cat_code(cat):
c = (cat or “”).lower()
for key, code in [(“hallucin”, “Hallu”), (“ocr”, “OCR”), (“context”, “Ctx”),
(“fine_grain”, “FGR”), (“fine-grain”, “FGR”),
(“compar”, “Comp”), (“local”, “Loc”), (“position”, “Loc”),
(“depth”, “Depth”), (“3d”, “Depth”),
(“attribut”, “Attr”), (“count”, “Count”),
(“relation”, “VRel”)]:
if key in c:
return code
return cat[:6].title()
CODE_ORDER = [“VRel”, “Count”, “Attr”, “Depth”, “Loc”, “Comp”, “FGR”, “Ctx”, “OCR”, “Hallu”]
CODE_FULL = {“VRel”: “visual relation”, “Count”: “counting”, “Attr”: “attribute”,
“Depth”: “depth & 3D”, “Loc”: “localization”, “Comp”: “comparison”,
“FGR”: “fine-grained recog.”, “Ctx”: “contextual integration”,
“OCR”: “OCR”, “Hallu”: “perception hallucination”}
for r in RECORDS:
r[“code”] = cat_code(r[“category”])
df = pd.DataFrame([{k: v for k, v in r.items() if k != “images”} for r in RECORDS])
def answer_type(a):
a = a.strip()
if re.fullmatch(r”-?d+”, a): return “integer”
if re.fullmatch(r”-?d*.d+”, a): return “decimal”
if re.fullmatch(r”(?i)(yes|no|true|false)”, a): return “boolean”
if re.fullmatch(r”(?i)[A-H]”, a): return “letter”
if len(a.split()) == 1: return “single-word”
return “phrase”
df[“ans_type”] = df[“answer”].map(answer_type)
print(“=” * 78)
print(“§4 DATASET PROFILE (stratified subset — the card reports 3,000 total)”)
print(“=” * 78)
print(“n– atomic capabilities present –“)
print(df.groupby(“code”).agg(n=(“index”, “size”),
mean_imgs=(“n_images”, “mean”),
mean_qlen=(“q_chars”, “mean”)).round(2).to_string())
print(“n– answer surface forms –“)
print(df[“ans_type”].value_counts().to_string())
print(“n– images per question –“)
print(df[“n_images”].value_counts().sort_index().to_string())
print(f”n– multi-image questions: {(df.n_images > 1).mean():.1%} of the subset”)
print(f”– median longest image edge: {df.max_side.median():.0f}px ”
f”(max {df.max_side.max():.0f}px)”)
print(“n– provenance (top source benchmarks) –“)
print(df[“source_bmk”].value_counts().head(8).to_string())
print(f”n– newly-authored (source_bmk == ‘NA’): {(df.source_bmk==’NA’).mean():.1%} ”
f”(card: 40% authored / 60% decomposed)n”)
def hf_full_stats(repo, split=”train”, config=”default”):
try:
r = requests.get(“https://datasets-server.huggingface.co/statistics”,
params={“dataset”: repo, “config”: config, “split”: split},
timeout=30)
r.raise_for_status()
for col in r.json().get(“statistics”, []):
if col[“column_name”] == “error_category”:
freq = col[“column_statistics”].get(“frequencies”, {})
if freq:
tot = sum(freq.values())
print(“– FULL-CORPUS capability distribution (3,000 rows, via datasets-server) –“)
for k, v in sorted(freq.items(), key=lambda x: -x[1]):
print(f” {cat_code(k):6s} {k:34s} {v:5d} {v/tot:6.1%}”)
print()
return freq
except Exception as e:
print(f”[stats] datasets-server unavailable ({type(e).__name__}); ”
f”using subset statistics onlyn”)
return None
FULL_FREQ = hf_full_stats(CFG[“REPO”], CFG[“SPLIT”])
if CFG[“SHOW_PLOTS”]:
fig, ax = plt.subplots(1, 3, figsize=(13, 3.4))
order = [c for c in CODE_ORDER if c in set(df.code)] +
[c for c in sorted(set(df.code)) if c not in CODE_ORDER]
df.code.value_counts().reindex(order).plot.bar(ax=ax[0], color=”#4C72B0″)
ax[0].set_title(“Questions per atomic capability”); ax[0].set_xlabel(“”)
df.n_images.value_counts().sort_index().plot.bar(ax=ax[1], color=”#DD8452″)
ax[1].set_title(“Images per question”); ax[1].set_xlabel(“# images”)
df.ans_type.value_counts().plot.barh(ax=ax[2], color=”#55A868″)
ax[2].set_title(“Answer surface form”)
plt.tight_layout(); plt.show()
We decode images from data URIs, raw base64 strings, byte arrays, PIL objects, and Hugging Face image dictionaries into a consistent RGB format. We normalize every dataset row into a structured record containing question text, answers, images, capability labels, dimensions, placeholder counts, and source information. We then analyze capability coverage, answer formats, image counts, resolution characteristics, and source benchmarks while visualizing the resulting dataset profile.
Copy CodeCopiedUse a different Browserdef show_record(rec, max_imgs=4):
imgs = rec[“images”][:max_imgs]
n = len(imgs)
fig, axes = plt.subplots(1, n, figsize=(4.2 * n, 4.2))
axes = np.atleast_1d(axes)
for a, im in zip(axes, imgs):
a.imshow(im); a.axis(“off”)
q = re.sub(r”s+”, ” “, rec[“problem”])
q = (q[:150] + “…”) if len(q) > 150 else q
fig.suptitle(f”[{rec[‘code’]} · {rec[‘category’]}] {q}n”
f”gold = {rec[‘answer’]!r} | src = {rec[‘source_bmk’]}”,
fontsize=9, y=1.06)
plt.tight_layout(); plt.show()
if CFG[“SHOW_PLOTS”]:
print(“=” * 78); print(“§5 ONE EXEMPLAR PER CAPABILITY”); print(“=” * 78)
seen = set()
for rec in RECORDS:
if rec[“code”] not in seen:
seen.add(rec[“code”]); show_record(rec)
if len(seen) >= 4:
break
SYSTEM_PROMPT = (
“You are a careful visual perception assistant. Examine the image(s) closely ”
“before answering. Every question has a short, uniquely determined answer.n”
“Reason briefly if needed, then end your reply with exactly one line:n”
“Answer: <your final short answer>n”
“Give only the value (a number, word, or short phrase) after ‘Answer:’ — ”
“no units, no explanation, no full sentence.”
)
def build_payload(rec, max_side, quality):
“””Returns (interleaved_parts, resized_pils, data_uris).”””
resized, uris = [], []
for im in rec[“images”]:
pil, uri = shrink(im, max_side, quality)
resized.append(pil); uris.append(uri)
parts = split_on_placeholders(rec[“problem”], len(resized))
if rec[“hint”]:
parts.append((“text”, f”Hint: {rec[‘hint’]}”))
return parts, resized, uris
def parts_to_openai(parts, uris):
content = []
for kind, val in parts:
if kind == “text”:
content.append({“type”: “text”, “text”: val})
else:
content.append({“type”: “image_url”, “image_url”: {“url”: uris[val]}})
return [{“role”: “system”, “content”: SYSTEM_PROMPT},
{“role”: “user”, “content”: content}]
We display representative benchmark examples by arranging the associated images into readable grids and presenting each question with its capability, reference answer, and source. We define a strict multimodal system prompt that instructs the evaluated model to inspect all images and return a concise final answer in a consistent format. We also resize images, preserve their placement relative to question placeholders, and convert the resulting content into OpenAI-compatible multimodal messages.
Copy CodeCopiedUse a different Browserclass Backend:
name = “base”
def predict(self, rec): raise NotImplementedError
def predict_batch(self, recs):
return [self.predict(r) for r in recs]
class BlindPriorBackend(Backend):
“””Text-only floor. Answers using the *answer prior* conditioned on the
surface form the question implies — no pixels are ever read.
This is the control condition that makes an accuracy number meaningful:
‘How many hinges?’ has a guessable prior (small integers dominate). If a
vision model barely beats this, it isn’t perceiving, it’s guessing.”””
name = “blind-prior”
def __init__(self, records, seed=0):
self.rng = random.Random(seed)
self.by_type = defaultdict(list)
for r in records:
self.by_type[answer_type(r[“answer”])].append(r[“answer”])
self.all = [r[“answer”] for r in records]
def predict(self, rec):
q = rec[“problem”].lower()
if re.search(r”how many|number of|count”, q):
pool = self.by_type.get(“integer”) or self.all
elif re.search(r”bisb.*?|does |are there”, q):
pool = self.by_type.get(“boolean”) or self.all
else:
pool = self.all
return f”Answer: {self.rng.choice(pool)}”
class OpenAICompatBackend(Backend):
“””Works with OpenAI, Moonshot/Kimi, OpenRouter, Together, vLLM, LM Studio…
anything exposing POST {base}/chat/completions with image_url content.”””
def __init__(self, base, key, model, max_tokens, workers, max_side, quality):
self.base, self.key, self.model = base.rstrip(“/”), key, model
self.max_tokens, self.workers = max_tokens, workers
self.max_side, self.quality = max_side, quality
self.name = f”api:{model}”
def _one(self, rec, retries=4):
parts, _, uris = build_payload(rec, self.max_side, self.quality)
body = {“model”: self.model, “messages”: parts_to_openai(parts, uris),
“max_tokens”: self.max_tokens, “temperature”: 0}
for a in range(retries):
try:
r = requests.post(f”{self.base}/chat/completions”,
headers={“Authorization”: f”Bearer {self.key}”,
“Content-Type”: “application/json”},
json=body, timeout=180)
if r.status_code in (429, 500, 502, 503, 529):
time.sleep(2 ** a + random.random()); continue
r.raise_for_status()
return r.json()[“choices”][0][“message”][“content”]
except Exception as e:
if a == retries – 1:
return f”__ERROR__ {type(e).__name__}: {e}”
time.sleep(2 ** a + random.random())
return “__ERROR__ exhausted”
def predict(self, rec):
return self._one(rec)
def predict_batch(self, recs):
out = [None] * len(recs)
with ThreadPoolExecutor(max_workers=self.workers) as ex:
futs = {ex.submit(self._one, r): i for i, r in enumerate(recs)}
done = 0
for f in as_completed(futs):
out[futs[f]] = f.result(); done += 1
print(f” [api] {done}/{len(recs)}”, end=”r”)
print()
return out
class LocalVLMBackend(Backend):
“””Small open VLM on a Colab GPU (T4 works for ~2-3B in fp16).”””
def __init__(self, model_id, max_new, max_side):
import torch
from transformers import AutoProcessor, AutoModelForImageTextToText
self.torch, self.max_new, self.max_side = torch, max_new, max_side
self.name = f”local:{model_id.split(‘/’)[-1]}”
dtype = torch.float16 if torch.cuda.is_available() else torch.float32
print(f”[local] loading {model_id} ({dtype})…”)
self.proc = AutoProcessor.from_pretrained(model_id)
self.model = AutoModelForImageTextToText.from_pretrained(
model_id, torch_dtype=dtype,
device_map=”auto” if torch.cuda.is_available() else None)
self.model.eval()
def predict(self, rec):
parts, pils, _ = build_payload(rec, self.max_side, 90)
content = [{“type”: “image”, “image”: pils[v]} if k == “image”
else {“type”: “text”, “text”: v} for k, v in parts]
msgs = [{“role”: “system”, “content”: [{“type”: “text”, “text”: SYSTEM_PROMPT}]},
{“role”: “user”, “content”: content}]
try:
inputs = self.proc.apply_chat_template(
msgs, add_generation_prompt=True, tokenize=True,
return_dict=True, return_tensors=”pt”).to(self.model.device)
except Exception:
text = self.proc.apply_chat_template(msgs, add_generation_prompt=True)
inputs = self.proc(text=[text], images=pils, return_tensors=”pt”).to(self.model.device)
with self.torch.inference_mode():
ids = self.model.generate(**inputs, max_new_tokens=self.max_new, do_sample=False)
gen = ids[0][inputs[“input_ids”].shape[-1]:]
return self.proc.decode(gen, skip_special_tokens=True)
def predict_batch(self, recs):
out = []
for i, r in enumerate(recs):
out.append(self.predict(r))
print(f” [local] {i+1}/{len(recs)}”, end=”r”)
print()
return out
def make_backend():
b = CFG[“BACKEND”]
if b == “api”:
assert CFG[“API_KEY”], “Set CFG[‘API_KEY’] (or the PB_API_KEY env var).”
return OpenAICompatBackend(CFG[“API_BASE”], CFG[“API_KEY”], CFG[“API_MODEL”],
CFG[“API_MAX_TOKENS”], CFG[“API_WORKERS”],
CFG[“MAX_IMAGE_SIDE”], CFG[“JPEG_QUALITY”])
if b == “local”:
return LocalVLMBackend(CFG[“LOCAL_MODEL”], CFG[“LOCAL_MAX_NEW”], CFG[“MAX_IMAGE_SIDE”])
return BlindPriorBackend(RECORDS, CFG[“SEED”])
WORD2NUM = {w: i for i, w in enumerate(
“zero one two three four five six seven eight nine ten eleven twelve ”
“thirteen fourteen fifteen sixteen seventeen eighteen nineteen twenty”.split())}
ARTICLES = {“a”, “an”, “the”, “is”, “are”, “there”, “it”, “of”}
def extract_answer(raw):
“””Pull the final short answer out of free-form model text.”””
if raw is None:
return “”
t = str(raw).strip()
if t.startswith(“__ERROR__”):
return “”
m = re.findall(r”\boxed{([^}]*)}”, t)
if m:
return m[-1].strip()
m = re.findall(r”(?i)bfinal answers*[:-]s*(.+)”, t)
if m:
return m[-1].strip().split(“n”)[0].strip()
m = re.findall(r”(?i)^s*answers*[:-]s*(.+)$”, t, re.M)
if m:
return m[-1].strip()
lines = [l.strip() for l in t.split(“n”) if l.strip()]
return lines[-1] if lines else “”
def normalize(s):
s = str(s).strip().lower()
s = re.sub(r”^**|**$”, “”, s)
s = re.sub(r”[u2018u2019u201cu201d]”, “‘”, s)
s = re.sub(r”[.,;:!?'”()[]]+$”, “”, s)
s = re.sub(r”^[.,;:!?'”()[]]+”, “”, s)
s = s.replace(“%”, ” percent “).replace(“$”, ” dollar “)
s = re.sub(r”(d),(d{3})b”, r”12″, s)
s = re.sub(r”s+”, ” “, s).strip()
toks = [WORD2NUM.get(t, t) for t in s.split()]
toks = [str(t) for t in toks if str(t) not in ARTICLES]
return ” “.join(toks).strip()
def as_number(s):
s = normalize(s)
m = re.fullmatch(r”-?d+(?:.d+)?”, s)
if m:
return float(s)
m = re.findall(r”-?d+(?:.d+)?”, s)
return float(m[0]) if len(m) == 1 else None
def rule_judge(pred_raw, gold, rel_tol=0.0):
pred = extract_answer(pred_raw)
if not pred:
return 0, “empty”
p, g = normalize(pred), normalize(gold)
if p == g:
return 1, “exact”
pn, gn = as_number(p), as_number(g)
if pn is not None and gn is not None:
if pn == gn:
return 1, “numeric”
if rel_tol > 0 and gn != 0 and abs(pn – gn) / abs(gn) <= rel_tol:
return 1, “numeric~tol”
return 0, “numeric-mismatch”
if re.fullmatch(r”(yes|true)”, g) and re.search(r”b(yes|true)b”, p): return 1, “bool”
if re.fullmatch(r”(no|false)”, g) and re.search(r”b(no|false)b”, p): return 1, “bool”
if len(g.split()) <= 4 and re.search(rf”(?<!w){re.escape(g)}(?!w)”, p):
return 1, “contains”
return 0, “mismatch”
LLM_JUDGE_PROMPT = (
“You grade a visual-question answer. Reply with exactly one token: ”
“CORRECT or INCORRECT.nQuestion: {q}nReference answer: {g}n”
“Model answer: {p}nSemantically equivalent to the reference (ignoring ”
“phrasing, units, formatting)?”)
def llm_judge(pred_raw, gold, question):
“””Mirrors the paper’s protocol (they use GPT-oss-120B as the judge,
reporting 99.7% agreement with humans on a 300-sample audit).”””
pred = extract_answer(pred_raw)
if not pred:
return 0, “empty”
ok, why = rule_judge(pred_raw, gold)
if ok:
return 1, “rule-shortcut”
try:
r = requests.post(f”{CFG[‘API_BASE’].rstrip(‘/’)}/chat/completions”,
headers={“Authorization”: f”Bearer {CFG[‘API_KEY’]}”},
json={“model”: CFG[“API_MODEL”], “temperature”: 0, “max_tokens”: 5,
“messages”: [{“role”: “user”, “content”:
LLM_JUDGE_PROMPT.format(q=question, g=gold, p=pred)}]},
timeout=60)
v = r.json()[“choices”][0][“message”][“content”].strip().upper()
return (1, “llm”) if v.startswith(“CORRECT”) else (0, “llm”)
except Exception:
return ok, why + “+judge-failed”
_JUDGE_TESTS = [
(“Answer: 15400”, “15400”, 1), (“The score is 15,400.”, “15400”, 1),
(“Answer: three”, “3”, 1), (“Answer: 4 hinges”, “4”, 1),
(“\boxed{8}”, “8”, 1), (“Answer: 7”, “8”, 0),
(“Answer: Yes”, “yes”, 1), (“I cannot tell.”, “5”, 0),
(“Final answer: blue”, “Blue”, 1),
]
_fails = [(p, g, e) for p, g, e in _JUDGE_TESTS if rule_judge(p, g)[0] != e]
print(f”[judge] self-test: {len(_JUDGE_TESTS)-len(_fails)}/{len(_JUDGE_TESTS)} passed”
+ (f” FAILURES: {_fails}” if _fails else “”))
We create a shared backend interface and implement blind-prior, OpenAI-compatible API, and local Hugging Face vision-language model backends. We build answer-extraction and normalization utilities that handle numbers, written number words, punctuation, formatted responses, Boolean answers, and short phrases. We then apply rule-based or optional LLM-assisted judging and run offline self-tests to verify that the evaluator handles common response variations correctly.
Copy CodeCopiedUse a different Browserdef run_eval(records, backend):
print(f”n[eval] backend = {backend.name} on {len(records)} questions”)
t0 = time.time()
preds = backend.predict_batch(records)
rows = []
for rec, raw in zip(records, preds):
if CFG[“JUDGE”] == “llm” and CFG[“API_KEY”]:
ok, how = llm_judge(raw, rec[“answer”], rec[“problem”])
else:
ok, how = rule_judge(raw, rec[“answer”], CFG[“NUM_REL_TOL”])
rows.append(dict(index=rec[“index”], code=rec[“code”], category=rec[“category”],
source_bmk=rec[“source_bmk”], n_images=rec[“n_images”],
q_chars=rec[“q_chars”], max_side=rec[“max_side”],
ans_type=answer_type(rec[“answer”]),
gold=rec[“answer”], pred=extract_answer(raw),
raw=str(raw)[:2000], correct=ok, how=how))
print(f”[eval] done in {time.time()-t0:.1f}s”)
return pd.DataFrame(rows)
def bootstrap_ci(vals, n_boot=4000, seed=0):
a = np.asarray(vals, dtype=float)
if a.size == 0:
return (float(“nan”), float(“nan”))
rng = np.random.default_rng(seed)
means = a[rng.integers(0, a.size, (n_boot, a.size))].mean(axis=1)
return tuple(np.percentile(means, [2.5, 97.5]) * 100)
def report(res, label):
print(“n” + “=” * 78)
print(f”§9 RESULTS — {label}”)
print(“=” * 78)
lo, hi = bootstrap_ci(res.correct)
print(f”nOVERALL accuracy: {res.correct.mean()*100:5.1f}% ”
f”95% CI [{lo:.1f}, {hi:.1f}] (n={len(res)})”)
print(“(card: no frontier model exceeds 60% overall)n”)
print(“– per atomic capability –“)
tab = []
for code, g in res.groupby(“code”):
l, h = bootstrap_ci(g.correct)
tab.append(dict(code=code, capability=CODE_FULL.get(code, code),
n=len(g), acc=g.correct.mean() * 100, lo=l, hi=h))
t = pd.DataFrame(tab).sort_values(“acc”, ascending=False)
print(t.to_string(index=False, float_format=lambda x: f”{x:6.1f}”))
print(“n– difficulty slices –“)
res = res.copy()
res[“img_bucket”] = np.where(res.n_images > 1, “multi-image”, “single-image”)
res[“res_bucket”] = pd.cut(res.max_side, [0, 800, 1600, 10**6],
labels=[“<800px”, “800-1600px”, “>1600px”])
for col in [“img_bucket”, “res_bucket”, “ans_type”]:
s = res.groupby(col, observed=True).correct.agg([“size”, “mean”])
s[“mean”] = (s[“mean”] * 100).round(1)
print(f”n by {col}:n{s.rename(columns={‘size’:’n’,’mean’:’acc%’}).to_string()}”)
print(“n– judge decision breakdown –“)
print(res.how.value_counts().to_string())
errs = res[res.correct == 0]
if len(errs):
print(“n– sample failures –“)
for _, r in errs.head(5).iterrows():
print(f” [{r.code}] gold={r.gold!r:>14} pred={r[‘pred’]!r:>20} ({r.how})”)
return t
BACKEND = make_backend()
RES = run_eval(RECORDS, BACKEND)
PER_CAP = report(RES, BACKEND.name)
LEADERBOARD = {
“GPT-5.6-Sol”: [59.7, 69.7, 62.4, 62.1, 55.5, 76.7, 67.0, 55.9, 60.0, 54.9, 26.9],
“Kimi K3”: [58.5, 68.2, 59.7, 59.4, 52.4, 70.3, 59.1, 55.9, 53.3, 61.2, 41.7],
“Claude-Fable-5”: [57.2, 58.5, 52.9, 60.9, 51.5, 70.4, 56.1, 51.6, 59.8, 64.3, 45.0],
“Gemini-3.1-Pro”: [56.2, 58.8, 56.9, 61.8, 50.0, 52.7, 61.7, 54.8, 61.2, 64.3, 40.6],
“Seed-2.1-Pro”: [55.0, 57.6, 51.2, 58.2, 43.6, 50.0, 59.5, 56.6, 60.4, 66.7, 49.8],
“Qwen3.5-397B-A17B”:[47.5, 55.2, 49.1, 53.0, 44.6, 46.7, 49.8, 44.8, 50.2, 52.9, 26.9],
“Gemma-4-31B”: [40.7, 42.7, 33.9, 40.3, 39.1, 44.9, 43.7, 39.0, 45.9, 46.7, 32.1],
“GLM-4.6V”: [32.5, 35.2, 31.8, 35.2, 29.1, 30.6, 34.8, 29.3, 33.7, 39.2, 26.9],
}
LB = pd.DataFrame(LEADERBOARD, index=[“Overall”] + CODE_ORDER).T
print(“n” + “=” * 78)
print(“§10 OFFICIAL LEADERBOARD (subset, accuracy %)”)
print(“=” * 78)
print(LB.to_string())
print(“nNote the structural finding from the card: Hallu is the weakest column ”
“almost everywhere,nand models with near-identical Overall scores have ”
“very different capability profiles.”)
def radar(per_cap_df, label, compare=(“GPT-5.6-Sol”, “Gemma-4-31B”)):
codes = [c for c in CODE_ORDER if c in set(per_cap_df.code)]
if len(codes) < 3:
print(“[radar] need >=3 capabilities”); return
vals = per_cap_df.set_index(“code”).acc.reindex(codes).fillna(0).tolist()
ang = np.linspace(0, 2 * np.pi, len(codes), endpoint=False).tolist()
close = lambda v: v + v[:1]
fig, ax = plt.subplots(figsize=(6.4, 6.4), subplot_kw=dict(polar=True))
ax.plot(close(ang), close(vals), lw=2.4, color=”#C44E52″, label=label)
ax.fill(close(ang), close(vals), alpha=.18, color=”#C44E52″)
for m in compare:
if m in LB.index:
v = LB.loc[m, codes].tolist()
ax.plot(close(ang), close(v), lw=1.3, ls=”–“, alpha=.85, label=m)
ax.set_xticks(ang)
ax.set_xticklabels(codes)
ax.set_ylim(0, 100)
ax.set_yticks([20, 40, 60, 80])
ax.set_title(“PerceptionBench capability profile”, pad=24)
ax.legend(loc=”upper right”, bbox_to_anchor=(1.32, 1.12), fontsize=8)
plt.tight_layout(); plt.show()
if CFG[“SHOW_PLOTS”]:
radar(PER_CAP, BACKEND.name)
fig, ax = plt.subplots(figsize=(7, 3.2))
s = LB[“Overall”].sort_values()
ax.barh(s.index, s.values, color=”#8C8C8C”)
ax.barh([BACKEND.name], [RES.correct.mean() * 100], color=”#C44E52″)
ax.axvline(60, ls=”–“, c=”k”, lw=1)
ax.text(60.5, -.4, “60% ceiling: unbeaten”, fontsize=8)
ax.set_xlabel(“Overall accuracy (%)”); ax.set_title(“Your run vs. the leaderboard”)
plt.tight_layout(); plt.show()
tag = re.sub(r”[^A-Za-z0-9_.-]”, “_”, BACKEND.name)
p_pred = os.path.join(CFG[“OUT_DIR”], f”predictions_{tag}.jsonl”)
p_cap = os.path.join(CFG[“OUT_DIR”], f”per_capability_{tag}.csv”)
p_meta = os.path.join(CFG[“OUT_DIR”], f”run_meta_{tag}.json”)
with open(p_pred, “w”) as f:
for _, r in RES.iterrows():
f.write(json.dumps(r.to_dict(), default=str) + “n”)
PER_CAP.to_csv(p_cap, index=False)
json.dump({“config”: {k: v for k, v in CFG.items() if “KEY” not in k},
“backend”: BACKEND.name, “n_questions”: len(RES),
“rows_scanned”: N_SCANNED,
“overall_acc”: float(RES.correct.mean() * 100),
“ci95”: list(bootstrap_ci(RES.correct)),
“timestamp”: time.strftime(“%Y-%m-%dT%H:%M:%S”)},
open(p_meta, “w”), indent=2)
print(f”n[export] {p_pred}n[export] {p_cap}n[export] {p_meta}”)
print(“n” + “=” * 78)
print(“DONE. Next steps:”)
print(” 1) CFG[‘BACKEND’]=’api’ + PB_API_KEY/PB_API_BASE/PB_API_MODEL -> score a real MLLM”)
print(” 2) CFG[‘BACKEND’]=’local’ on a GPU runtime -> score an open 2-3B VLM”)
print(” 3) CFG[‘JUDGE’]=’llm’ -> reproduce the paper’s LLM-as-judge protocol”)
print(” 4) Raise N_PER_CATEGORY / MAX_SCAN, or LOAD_MODE=’full’ for all 3,000 rows”)
print(” 5) Ablations worth running: crop-to-region vs. full image, image resolution”)
print(” sweep (MAX_IMAGE_SIDE 512/1024/2048), and CoT-on vs. CoT-off prompts”)
print(“=” * 78)
We execute the selected backend across all prepared records, judge every prediction, and store the results in a structured DataFrame for analysis. We calculate overall and per-capability accuracy, bootstrap confidence intervals, difficulty slices, failure examples, and comparisons with the included benchmark leaderboard. We finally generate capability visualizations and export predictions, capability reports, configuration metadata, accuracy statistics, and reproducibility details as JSONL, CSV, and JSON files.
In conclusion, we established a modular and reproducible framework for evaluating multimodal models on PerceptionBench. We handled the full workflow from resilient dataset ingestion and image preprocessing to prompt construction, backend execution, answer extraction, automated judging, statistical analysis, visualization, and artifact export. We can run the pipeline without an API key or GPU using the blind-prior baseline, and we can switch to an API-hosted or local vision-language model by changing the backend configuration. The resulting reports allow us to move beyond a single overall accuracy score and inspect how each model performs across individual visual capabilities, multi-image questions, image resolutions, and answer formats. We also created a foundation for further experiments involving prompt variations, image-resolution sweeps, cropping strategies, judge comparisons, and full-dataset evaluations.
Check out the Full Codes here. Also, feel free to follow us on Twitter and don’t forget to join our 150k+ML SubReddit and Subscribe to our Newsletter. Wait! are you on telegram? now you can join us on telegram as well.
Need to partner with us for promoting your GitHub Repo OR Hugging Face Page OR Product Release OR Webinar etc.? Connect with us
The post Evaluating Multimodal Vision Models with Moonshot PerceptionBench Using Robust Data Loading and Automated Judging appeared first on MarkTechPost.
