Automating VCF 9.1 VPC Networking with PowerCLI: IP Blocks, Subnets, NAT, and External IPs

TL;DR

VCF 9.1 expands the VMware.VimAutomation.Vpc module so PowerCLI can build much more of the VPC networking foundation, including IP blocks, external connections, transit gateways, connectivity profiles, VPCs, subnets, and external-IP assignments.

The practical automation pattern is to build provider-owned connectivity first, create application-owned VPC objects second, and publish selected private workloads by assigning an external IP from the connectivity profile.

The documented high-level cmdlet set does not expose a New-VpcNatRule command. Default outbound SNAT is enabled on the connectivity profile, while external-IP assignment on a VM network adapter drives the supported workload-publishing workflow. NAT state can then be inspected with Get-VpcNatRule.

This tutorial provides an end-to-end script, validation commands, sample output, troubleshooting guidance, and a rollback script that protects shared provider networking by default.

Introduction

PowerCLI has traditionally been strongest when the infrastructure object already existed. The network team created port groups and routed VLANs, then the virtualization team automated virtual machines against those prepared networks.

VCF 9.1 changes that operating boundary. The VPC module now exposes high-level cmdlets for objects that sit below the application subnet, including IP blocks, external connections, transit gateways, and connectivity profiles. That makes it possible to automate a complete VPC path instead of stopping at New-Vpc and New-VpcSubnet.

The opportunity is significant, but so is the blast radius. An application VPC can often be treated as disposable. An external connection, transit gateway, connectivity profile, or enterprise IP block may be shared by many VPCs.

A production script therefore needs more than a sequence of New-* commands. It needs ownership boundaries, validation, deterministic naming, dependency-aware rollback, and accurate handling of NAT and external IP assignments.

This walkthrough builds those controls into the automation rather than adding them after deployment.

What You Will Build

By the end of the walkthrough, you will have a PowerCLI workflow that:

connects to the VCF 9.1 workload-domain vCenter

explicitly loads the VPC module

validates the required span and edge cluster

creates an external connection backed by a routed VLAN

creates external and private transit-gateway IP blocks

creates a transit gateway and connectivity profile

enables north-south services and default outbound SNAT

creates an application VPC with three private subnets

connects a VM network adapter to a private VPC subnet

assigns either a requested or automatically allocated external IP

validates subnet status and NAT state

rolls back application objects without deleting shared provider constructs

The script is intentionally opinionated. It separates provider-owned networking from application-owned networking because those layers usually have different owners, approval paths, privileges, and lifecycles.

How the VPC Networking Objects Fit Together

The most important detail is dependency order. A VPC cannot consume a connectivity profile that does not exist, and a connectivity profile cannot provide external IPs or default SNAT without the required transit, IP, and service objects beneath it.

The divider is an operational boundary, not only a technical one.

Provider objects should normally be created by a network-platform pipeline and reused by application pipelines. This article creates both layers in one script so the full dependency chain is visible, but the rollback script does not delete provider objects unless an explicit switch is supplied.

The NAT Automation Boundary

VCF VPC networking supports default outbound SNAT and external-IP-based workload publishing, but the high-level PowerCLI surface does not treat every NAT rule as a directly authored object.

The supported pattern used here is:

Enable default outbound SNAT on the connectivity profile.

Associate an external IP block with that profile.

Connect a VM adapter to a VPC subnet.

Assign a specific external IP or request automatic allocation.

Inspect the resulting NAT state with Get-VpcNatRule.

This distinction matters because a script that invents New-VpcNatRule would look plausible but would not match the documented command set.

For custom NAT policies beyond the high-level workflow, use the appropriate supported API or SDK surface after validating the exact VCF 9.1 endpoint and object model.

Public subnets and external-IP assignments also solve different problems.

A public subnet is directly routed through the VPC architecture. An external IP assigned to a workload on a private subnet provides translated reachability without changing the private subnet’s access mode.

The script uses private subnets and publishes the sample VM from the private web tier so the external-IP and NAT behavior is explicit.

Prerequisites and Assumptions

Platform Prerequisites

You need:

a VCF 9.1 environment with VPC networking enabled

a workload-domain vCenter reachable from the PowerShell host

the current VCF.PowerCLI package installed

the VMware.VimAutomation.Vpc module available

permission to create VPC provider and application objects

an existing VPC span

an existing VPC edge cluster for centralized north-south services

an upstream VLAN, gateway, and routing configuration for the external network

a test VM with a network adapter that can be moved to the VPC subnet

a rollback port group if you plan to test the teardown script

Explicitly import VMware.VimAutomation.Vpc. Broadcom has documented environments where the module does not autoload even though VCF PowerCLI is installed.

Addressing Assumptions

Purpose
Example value
Ownership

External VLAN
3100
Physical or network platform team

External gateway
198.51.100.1/24
Upstream routing team

External allocation range
198.51.100.100-198.51.100.150
Network platform team

Requested VM external IP
198.51.100.120
Application allocation from approved pool

Transit subnet
100.64.16.0/21
Network platform team

Private TGW block
172.20.0.0/24
Network platform or project team

VPC private CIDR
10.42.0.0/16
Application or VPC owner

The 198.51.100.0/24 range is reserved for documentation and will not provide real enterprise connectivity.

Replace every sample value with addresses approved for your environment. Confirm upstream routing, VLAN reachability, overlap checks, address reservations, and ownership before execution.

Preflight Commands

Run these commands before the deployment script:

Get-Module VCF.PowerCLI -ListAvailable |
Sort-Object Version -Descending |
Select-Object -First 1 Name, Version

Import-Module VMware.VimAutomation.Vpc -ErrorAction Stop

Get-Command New-VpcIpBlock,
New-VpcExternalConnection,
New-VpcTransitGateway,
New-VpcConnectivityProfile,
New-Vpc,
New-VpcSubnet,
Get-VpcNatRule,
Get-VpcSubnetStatus

Successful output confirms that the advanced VPC cmdlets are available in the current session. It does not confirm that the connected account has permission to use them.

Confirm the Required Existing Objects

The deployment assumes that the span and edge cluster already exist.

Connect-VIServer -Server ‘vcsa01.corp.example’

Get-VpcSpan |
Select-Object Name, Id |
Format-Table -AutoSize

Get-VpcEdgeCluster |
Select-Object Name, Id |
Format-Table -AutoSize

Do not let the deployment script select an arbitrary span or edge cluster. Use exact names, validate that only one object matches, and confirm that the selected objects belong to the intended VCF networking design.

End-to-End PowerCLI Deployment Script

What You Must Change

Review every value in the configuration block.

At minimum, change:

the vCenter name

span name

edge cluster name

external VLAN

external gateway

external IP ranges

transit subnet

VPC private CIDR

VM name

fallback assumptions

requested external IP

The object-creation functions are rerunnable by name. If exactly one matching object exists, the script reuses it. If more than one object matches, the script stops rather than guessing.

Reuse is not full reconciliation. The helper does not automatically modify an existing object when its settings differ from the configuration block. The validation stage must detect that drift.

The final VM publishing action is deliberately not treated as blindly idempotent because changing an external IP or subnet can interrupt active workload connectivity.

Set-StrictMode -Version Latest
$ErrorActionPreference = ‘Stop’

$Config = [ordered]@{
VCenter = ‘vcsa01.corp.example’

SpanName = ‘default-span’
EdgeClusterName = ‘edge-cluster-01’

ExternalConnectionName = ‘dtd-ext-3100’
ExternalVlan = 3100
ExternalGatewayCidr = ‘198.51.100.1/24’

TransitGatewayName = ‘dtd-tgw’
TransitSubnet = ‘100.64.16.0/21’

ExternalIpBlockName = ‘dtd-external-ip’
ExternalIpCidr = ‘198.51.100.0/24’
ExternalIpRange = ‘198.51.100.100-198.51.100.150’
ExternalReservedIp = ‘198.51.100.100-198.51.100.109’

PrivateTgwIpBlockName = ‘dtd-private-tgw’
PrivateTgwCidr = ‘172.20.0.0/24’
PrivateTgwIpRange = ‘172.20.0.10-172.20.0.250’

ConnectivityProfileName = ‘dtd-vpc-profile’

VpcName = ‘dtd-app-vpc’
VpcPrivateCidr = ‘10.42.0.0/16’

Subnets = @(
[pscustomobject]@{
Name = ‘web-private’
AccessMode = ‘Private’
Cidr = ‘10.42.10.0/24’
Ipv4Size = $null
}
[pscustomobject]@{
Name = ‘app-private’
AccessMode = ‘Private’
Cidr = ‘10.42.20.0/24’
Ipv4Size = $null
}
[pscustomobject]@{
Name = ‘db-private’
AccessMode = ‘Private’
Cidr = ‘10.42.30.0/24’
Ipv4Size = $null
}
)

PublishedVmName = ‘api01’
PublishedAdapterName = ‘Network adapter 1’
PublishedSubnetName = ‘web-private’

# Use a valid address from ExternalIpRange.
# Set this to $null to request automatic allocation.
ExternalIp = ‘198.51.100.120’
}

function Get-ExactlyOneObject {
[CmdletBinding()]
param(
[Parameter(Mandatory)]
[string]$Label,

[Parameter(Mandatory)]
[scriptblock]$Lookup
)

$matches = @(& $Lookup)

if ($matches.Count -eq 0) {
throw “Required object not found: $Label”
}

if ($matches.Count -gt 1) {
throw “More than one object matched ‘$Label’. Use a unique name or scope.”
}

return $matches[0]
}

function Get-OrCreateObject {
[CmdletBinding()]
param(
[Parameter(Mandatory)]
[string]$Label,

[Parameter(Mandatory)]
[scriptblock]$Lookup,

[Parameter(Mandatory)]
[scriptblock]$Create
)

$matches = @(& $Lookup)

if ($matches.Count -gt 1) {
throw “More than one object matched ‘$Label’. Refusing ambiguous reuse.”
}

if ($matches.Count -eq 1) {
Write-Host “[EXISTS] $Label”
return $matches[0]
}

Write-Host “[CREATE] $Label”
return & $Create
}

if (-not (Get-Module -ListAvailable -Name VCF.PowerCLI)) {
throw ‘VCF.PowerCLI is not installed.’
}

Import-Module VCF.PowerCLI -ErrorAction Stop
Import-Module VMware.VimAutomation.Vpc -ErrorAction Stop

$credential = Get-Credential -Message “Credentials for $($Config.VCenter)”
$viServer = $null

try {
$viServer = Connect-VIServer `
-Server $Config.VCenter `
-Credential $credential

$span = Get-ExactlyOneObject `
-Label “Span ‘$($Config.SpanName)'” `
-Lookup {
Get-VpcSpan `
-Name $Config.SpanName `
-ErrorAction SilentlyContinue
}

$edgeCluster = Get-ExactlyOneObject `
-Label “Edge cluster ‘$($Config.EdgeClusterName)'” `
-Lookup {
Get-VpcEdgeCluster `
-Name $Config.EdgeClusterName `
-ErrorAction SilentlyContinue
}

$externalConnection = Get-OrCreateObject `
-Label “External connection ‘$($Config.ExternalConnectionName)'” `
-Lookup {
Get-VpcExternalConnection `
-Name $Config.ExternalConnectionName `
-ErrorAction SilentlyContinue
} `
-Create {
New-VpcExternalConnection `
-Name $Config.ExternalConnectionName `
-Vlan $Config.ExternalVlan `
-GatewayCidr $Config.ExternalGatewayCidr `
-Description ‘Managed by the DTD VPC PowerCLI workflow’
}

$externalIpBlock = Get-OrCreateObject `
-Label “External IP block ‘$($Config.ExternalIpBlockName)'” `
-Lookup {
Get-VpcIpBlock `
-Name $Config.ExternalIpBlockName `
-ErrorAction SilentlyContinue
} `
-Create {
New-VpcIpBlock `
-Name $Config.ExternalIpBlockName `
-Cidr $Config.ExternalIpCidr `
-IpRange $Config.ExternalIpRange `
-ReservedIp $Config.ExternalReservedIp `
-Visibility External `
-Description ‘Externally routed addresses for VPC services’
}

$privateTgwIpBlock = Get-OrCreateObject `
-Label “Private TGW IP block ‘$($Config.PrivateTgwIpBlockName)'” `
-Lookup {
Get-VpcIpBlock `
-Name $Config.PrivateTgwIpBlockName `
-ErrorAction SilentlyContinue
} `
-Create {
New-VpcIpBlock `
-Name $Config.PrivateTgwIpBlockName `
-Cidr $Config.PrivateTgwCidr `
-IpRange $Config.PrivateTgwIpRange `
-Visibility Private `
-Description ‘Private transit-gateway addressing for VPCs’
}

$transitGateway = Get-OrCreateObject `
-Label “Transit gateway ‘$($Config.TransitGatewayName)'” `
-Lookup {
Get-VpcTransitGateway `
-Name $Config.TransitGatewayName `
-ErrorAction SilentlyContinue
} `
-Create {
New-VpcTransitGateway `
-Name $Config.TransitGatewayName `
-TransitSubnet $Config.TransitSubnet `
-ExternalConnection $externalConnection `
-Span $span `
-Description ‘Transit gateway for the DTD application VPC pattern’
}

$connectivityProfile = Get-OrCreateObject `
-Label “Connectivity profile ‘$($Config.ConnectivityProfileName)'” `
-Lookup {
Get-VpcConnectivityProfile `
-Name $Config.ConnectivityProfileName `
-ErrorAction SilentlyContinue
} `
-Create {
New-VpcConnectivityProfile `
-Name $Config.ConnectivityProfileName `
-TransitGateway $transitGateway `
-ExternalIpBlock $externalIpBlock `
-PrivateTgwIpBlock $privateTgwIpBlock `
-EnableServiceGateway $true `
-EdgeCluster $edgeCluster `
-EnableDefaultSnat $true `
-Description ‘N-S services, external IP allocation, and default SNAT’
}

$vpc = Get-OrCreateObject `
-Label “VPC ‘$($Config.VpcName)'” `
-Lookup {
Get-Vpc `
-Name $Config.VpcName `
-ErrorAction SilentlyContinue
} `
-Create {
New-Vpc `
-Name $Config.VpcName `
-PrivateIp $Config.VpcPrivateCidr `
-ConnectivityProfile $connectivityProfile `
-Description ‘Application VPC created by PowerCLI’
}

$subnetObjects = @{}

foreach ($subnetSpec in $Config.Subnets) {
$subnet = Get-OrCreateObject `
-Label “Subnet ‘$($subnetSpec.Name)'” `
-Lookup {
Get-VpcSubnet `
-Vpc $vpc `
-Name $subnetSpec.Name `
-ErrorAction SilentlyContinue
} `
-Create {
$subnetParameters = @{
Vpc = $vpc
Name = $subnetSpec.Name
AccessMode = $subnetSpec.AccessMode
DhcpMode = ‘Server’
Description = “Application subnet $($subnetSpec.Name)”
}

if ($subnetSpec.Cidr) {
$subnetParameters.IpAddress = $subnetSpec.Cidr
}
else {
$subnetParameters.Ipv4Size = $subnetSpec.Ipv4Size
}

New-VpcSubnet @subnetParameters
}

$subnetObjects[$subnetSpec.Name] = $subnet
}

$vm = Get-ExactlyOneObject `
-Label “VM ‘$($Config.PublishedVmName)'” `
-Lookup {
Get-VM `
-Name $Config.PublishedVmName `
-ErrorAction SilentlyContinue
}

$networkAdapter = Get-ExactlyOneObject `
-Label “Adapter ‘$($Config.PublishedAdapterName)’ on ‘$($Config.PublishedVmName)'” `
-Lookup {
Get-NetworkAdapter `
-VM $vm `
-Name $Config.PublishedAdapterName `
-ErrorAction SilentlyContinue
}

$publishedSubnet = $subnetObjects[$Config.PublishedSubnetName]

if (-not $publishedSubnet) {
throw “Published subnet ‘$($Config.PublishedSubnetName)’ was not created.”
}

if ([string]::IsNullOrWhiteSpace([string]$Config.ExternalIp)) {
Write-Host “[PUBLISH] Requesting an automatic external IP for $($vm.Name)”

Set-NetworkAdapter `
-NetworkAdapter $networkAdapter `
-Subnet $publishedSubnet `
-AutoAssignExternalIp `
-Confirm:$false | Out-Null

$externalIpRequest = ‘Automatic allocation’
}
else {
$requestedExternalIp = [ipaddress]$Config.ExternalIp

Write-Host “[PUBLISH] Assigning external IP $requestedExternalIp to $($vm.Name)”

Set-NetworkAdapter `
-NetworkAdapter $networkAdapter `
-Subnet $publishedSubnet `
-ExternalIp $requestedExternalIp `
-Confirm:$false | Out-Null

$externalIpRequest = $requestedExternalIp.IPAddressToString
}

Start-Sleep -Seconds 5

$subnetStatus = @(Get-VpcSubnetStatus -Vpc $vpc)
$natRules = @(Get-VpcNatRule -Vpc $vpc)

[pscustomobject]@{
VCenter = $viServer.Name
Vpc = $vpc.Name
ConnectivityProfile = $connectivityProfile.Name
TransitGateway = $transitGateway.Name
SubnetCount = @($subnetObjects.Values).Count
SubnetStatusCount = $subnetStatus.Count
PublishedVm = $vm.Name
PublishedSubnet = $publishedSubnet.Name
ExternalIpRequest = $externalIpRequest
NatRuleCount = $natRules.Count
} | Format-List
}
finally {
if ($viServer) {
Disconnect-VIServer `
-Server $viServer `
-Confirm:$false | Out-Null
}
}

What the Script Does

The workflow follows the platform dependency chain rather than creating objects in an arbitrary order.

The external connection defines the VLAN and gateway-facing CIDR. The transit gateway binds that connection to an existing span and receives its own transit subnet.

The two IP blocks then describe:

external address allocation

private transit-gateway addressing

The connectivity profile combines those resources with an edge cluster, enables north-south services, and enables default outbound SNAT.

The application layer starts only after that provider foundation exists.

New-Vpc creates the private VPC address space. New-VpcSubnet creates three explicit Private access-mode subnets from the VPC-owned CIDR.

Those subnets consume space from 10.42.0.0/16. They do not consume the private TGW IP block. The private TGW block is attached to the provider profile so the same profile can support Private-TGW subnet allocation when that access mode is needed.

The VM adapter is then attached to web-private and receives either the requested external IP or an automatically allocated address.

The helper functions are intentionally strict. Reusing one exact object is reasonable. Silently selecting one of several identically named objects is not.

Validate the Deployment

A successful cmdlet return does not prove end-to-end connectivity.

Validation should cover:

object existence

object configuration

realized subnet status

VM attachment

NAT state

address ownership

upstream reachability

security policy

return routing

Validate the Provider Foundation

Import-Module VMware.VimAutomation.Vpc -ErrorAction Stop
Connect-VIServer -Server ‘vcsa01.corp.example’

Get-VpcIpBlock -Name ‘dtd-external-ip’ |
Format-List *

Get-VpcIpBlock -Name ‘dtd-private-tgw’ |
Format-List *

Get-VpcExternalConnection -Name ‘dtd-ext-3100’ |
Format-List *

Get-VpcTransitGateway -Name ‘dtd-tgw’ |
Format-List *

Get-VpcConnectivityProfile -Name ‘dtd-vpc-profile’ |
Format-List *

Check that:

the external block uses External visibility

the private TGW block uses Private visibility

the external range and reserved addresses are correct

the transit gateway references the intended span

the transit gateway references the expected external connection

the profile references the intended edge cluster

the profile references both IP blocks

north-south services are enabled

default outbound SNAT is enabled

Validate the VPC and Subnets

$vpc = Get-Vpc -Name ‘dtd-app-vpc’

$vpc |
Format-List *

Get-VpcSubnet -Vpc $vpc |
Select-Object Name, Id |
Format-Table -AutoSize

Get-VpcSubnetStatus -Vpc $vpc |
Format-List *

The status objects are more useful than inventory alone.

Inventory confirms that the desired objects exist. Status helps determine whether those objects were realized successfully by the underlying networking platform.

Validate the VM Attachment and NAT State

Get-VM -Name ‘api01’ |
Get-NetworkAdapter -Name ‘Network adapter 1’ |
Format-List Name, NetworkName, ConnectionState

Get-VpcNatRule -Vpc $vpc |
Format-List *

The NAT query is deliberately read-only. It confirms the platform-managed rules associated with default outbound SNAT and the workload external-IP assignment.

Rule names, identifiers, and the total rule count can vary by deployment and implementation state.

Add NAT Statistics to Validation

Where NAT statistics are available, add them to the evidence collection:

Get-VpcNatRule -Vpc $vpc |
Get-VpcNatRuleStatistics |
Format-List *

Statistics are useful after test traffic has been generated. A rule that exists but has no matching traffic may indicate that the test path, security policy, routing, or workload addressing is incorrect.

Expected Script Output

A fresh deployment should produce progress similar to this:

[CREATE] External connection ‘dtd-ext-3100’
[CREATE] External IP block ‘dtd-external-ip’
[CREATE] Private TGW IP block ‘dtd-private-tgw’
[CREATE] Transit gateway ‘dtd-tgw’
[CREATE] Connectivity profile ‘dtd-vpc-profile’
[CREATE] VPC ‘dtd-app-vpc’
[CREATE] Subnet ‘web-private’
[CREATE] Subnet ‘app-private’
[CREATE] Subnet ‘db-private’
[PUBLISH] Assigning external IP 198.51.100.120 to api01

VCenter : vcsa01.corp.example
Vpc : dtd-app-vpc
ConnectivityProfile : dtd-vpc-profile
TransitGateway : dtd-tgw
SubnetCount : 3
SubnetStatusCount : 3
PublishedVm : api01
PublishedSubnet : web-private
ExternalIpRequest : 198.51.100.120
NatRuleCount : 2

The NAT rule count above is illustrative, not a pass criterion.

Validate the actual rule objects and their translated addresses instead of expecting a fixed count.

Validate Data-Plane Connectivity

Complete the workflow with tests outside PowerCLI:

confirm the guest receives an address from web-private

confirm the expected default gateway and DNS settings

test communication between the application and database subnets

test outbound connectivity through default SNAT

test reachability to the assigned external IP from an approved upstream test point

confirm upstream routing or adjacency for the external block

confirm gateway firewall policy permits the required traffic

confirm distributed firewall policy permits the required traffic

verify return-path routing

verify that the external IP is recorded in the enterprise IPAM system

Object realization and packet forwarding are separate validation stages. Do not close the change based only on successful object creation.

Capture Deployment Evidence

A useful production script should preserve evidence rather than displaying everything only in the terminal.

$evidencePath = Join-Path `
-Path $PWD `
-ChildPath “vpc-evidence-$($Config.VpcName)-$(Get-Date -Format ‘yyyyMMdd-HHmmss’)”

New-Item `
-Path $evidencePath `
-ItemType Directory `
-Force | Out-Null

Get-Vpc -Name $Config.VpcName |
ConvertTo-Json -Depth 10 |
Set-Content -Path (Join-Path $evidencePath ‘vpc.json’)

Get-VpcSubnet -Vpc $vpc |
ConvertTo-Json -Depth 10 |
Set-Content -Path (Join-Path $evidencePath ‘subnets.json’)

Get-VpcSubnetStatus -Vpc $vpc |
ConvertTo-Json -Depth 10 |
Set-Content -Path (Join-Path $evidencePath ‘subnet-status.json’)

Get-VpcNatRule -Vpc $vpc |
ConvertTo-Json -Depth 10 |
Set-Content -Path (Join-Path $evidencePath ‘nat-rules.json’)

Get-VM -Name $Config.PublishedVmName |
Get-NetworkAdapter -Name $Config.PublishedAdapterName |
ConvertTo-Json -Depth 10 |
Set-Content -Path (Join-Path $evidencePath ‘network-adapter.json’)

Store the resulting evidence with the change ticket, pipeline run, or Git-controlled deployment record.

That evidence becomes valuable when troubleshooting drift, reviewing an incident, or proving which objects were created by a specific automation run.

Roll Back Safely

Rollback should reverse dependencies from the workload upward.

It should also preserve shared provider infrastructure unless the operator explicitly chooses a full teardown.

Default Rollback Behavior

The rollback script below:

removes the VM’s external IP assignment

moves the VM adapter to a fallback distributed port group

removes the application subnets

removes the application VPC

leaves the connectivity profile intact

leaves the transit gateway intact

leaves the external connection intact

leaves the provider IP blocks intact

never removes the existing span or edge cluster

Supplying -RemoveProviderObjects extends the rollback to provider objects created by the deployment script.

Before running rollback, confirm that no other VM uses the VPC subnets and no other VPC depends on the provider objects.

[CmdletBinding()]
param(
[switch]$RemoveProviderObjects
)

Set-StrictMode -Version Latest
$ErrorActionPreference = ‘Stop’

$Config = [ordered]@{
VCenter = ‘vcsa01.corp.example’

VpcName = ‘dtd-app-vpc’
PublishedVmName = ‘api01’
PublishedAdapterName = ‘Network adapter 1’
PublishedSubnetName = ‘web-private’
FallbackPortGroupName = ‘VM-Network-Fallback’

ConnectivityProfileName = ‘dtd-vpc-profile’
TransitGatewayName = ‘dtd-tgw’
ExternalConnectionName = ‘dtd-ext-3100’
ExternalIpBlockName = ‘dtd-external-ip’
PrivateTgwIpBlockName = ‘dtd-private-tgw’
}

Import-Module VCF.PowerCLI -ErrorAction Stop
Import-Module VMware.VimAutomation.Vpc -ErrorAction Stop

$credential = Get-Credential -Message “Credentials for $($Config.VCenter)”
$viServer = $null

try {
$viServer = Connect-VIServer `
-Server $Config.VCenter `
-Credential $credential

$vpc = Get-Vpc `
-Name $Config.VpcName `
-ErrorAction SilentlyContinue

if ($vpc) {
$publishedSubnet = Get-VpcSubnet `
-Vpc $vpc `
-Name $Config.PublishedSubnetName `
-ErrorAction SilentlyContinue

$vm = Get-VM `
-Name $Config.PublishedVmName `
-ErrorAction SilentlyContinue

if ($vm -and $publishedSubnet) {
$networkAdapter = Get-NetworkAdapter `
-VM $vm `
-Name $Config.PublishedAdapterName `
-ErrorAction SilentlyContinue

if ($networkAdapter) {
Write-Host ‘[ROLLBACK] Removing external IP assignment’

Set-NetworkAdapter `
-NetworkAdapter $networkAdapter `
-Subnet $publishedSubnet `
-UnassignExternalIp `
-Confirm:$false | Out-Null

$fallbackPortGroup = Get-VDPortgroup `
-Name $Config.FallbackPortGroupName `
-ErrorAction Stop

Write-Host ‘[ROLLBACK] Moving VM adapter to fallback port group’

Set-NetworkAdapter `
-NetworkAdapter $networkAdapter `
-Portgroup $fallbackPortGroup `
-Confirm:$false | Out-Null
}
}

Write-Host ‘[ROLLBACK] Removing application subnets’

@(Get-VpcSubnet `
-Vpc $vpc `
-ErrorAction SilentlyContinue) |
ForEach-Object {
Remove-VpcSubnet -Subnet $_
}

Write-Host ‘[ROLLBACK] Removing application VPC’

Remove-Vpc -Vpc $vpc
}

if ($RemoveProviderObjects) {
$confirmation = Read-Host `
‘Type REMOVE-PROVIDER to delete shared provider objects’

if ($confirmation -ne ‘REMOVE-PROVIDER’) {
throw ‘Provider-object removal was not confirmed.’
}

Write-Host ‘[ROLLBACK] Removing connectivity profile’

@(Get-VpcConnectivityProfile `
-Name $Config.ConnectivityProfileName `
-ErrorAction SilentlyContinue) |
ForEach-Object {
Remove-VpcConnectivityProfile `
-ConnectivityProfile $_
}

Write-Host ‘[ROLLBACK] Removing transit gateway’

@(Get-VpcTransitGateway `
-Name $Config.TransitGatewayName `
-ErrorAction SilentlyContinue) |
ForEach-Object {
Remove-VpcTransitGateway `
-TransitGateway $_
}

Write-Host ‘[ROLLBACK] Removing external connection’

@(Get-VpcExternalConnection `
-Name $Config.ExternalConnectionName `
-ErrorAction SilentlyContinue) |
ForEach-Object {
Remove-VpcExternalConnection `
-ExternalConnection $_
}

Write-Host ‘[ROLLBACK] Removing IP blocks’

@(
Get-VpcIpBlock `
-Name $Config.ExternalIpBlockName `
-ErrorAction SilentlyContinue

Get-VpcIpBlock `
-Name $Config.PrivateTgwIpBlockName `
-ErrorAction SilentlyContinue
) | ForEach-Object {
Remove-VpcIpBlock -IpBlock $_
}
}
}
finally {
if ($viServer) {
Disconnect-VIServer `
-Server $viServer `
-Confirm:$false | Out-Null
}
}

Run the default application-only rollback as follows:

./Remove-DtdVpc.ps1

Run a full teardown only after dependency review:

./Remove-DtdVpc.ps1 -RemoveProviderObjects

A rollback failure is often a useful safety signal.

It may indicate that:

a subnet still has attached workloads

a VPC still has dependent objects

a connectivity profile is still referenced

a transit gateway supports other VPCs

an external IP is still allocated

a supposedly dedicated provider object is actually shared

Do not respond to those failures by adding wildcard deletion or forced cleanup without understanding the remaining dependencies.

Troubleshooting Common Failures

VPC Cmdlets Are Not Recognized

Explicitly import the VPC module and verify the installed VCF.PowerCLI version.

Import-Module VMware.VimAutomation.Vpc -Force

Get-Command New-VpcIpBlock,
New-VpcTransitGateway,
New-VpcConnectivityProfile

Do not assume that importing only the umbrella module made every VPC cmdlet available in the current session.

The Script Finds More Than One Named Object

Do not remove the ambiguity check.

Duplicate names can exist across scopes, projects, or connected servers. Use unique naming, connect to one vCenter at a time, or extend the lookup with an appropriate server, project, or object-ID boundary.

An Existing Object Has the Correct Name but the Wrong Configuration

The helper functions reuse a single matching object. They do not reconcile every property.

Compare the existing object’s settings against the configuration block before proceeding:

Get-VpcExternalConnection -Name ‘dtd-ext-3100’ |
Format-List *

Get-VpcTransitGateway -Name ‘dtd-tgw’ |
Format-List *

Get-VpcConnectivityProfile -Name ‘dtd-vpc-profile’ |
Format-List *

In a production pipeline, detect drift and stop unless the operator has explicitly approved a change.

IP Block Creation Fails

Validate:

CIDR syntax

start and end addresses

reserved-address ranges

address overlap

visibility

upstream ownership

whether the requested block already exists under a different name

The platform can reject an invalid object, but it cannot determine whether the enterprise network team has approved the address space.

Transit Gateway Creation Fails

Validate that:

the span exists

the external connection exists

the transit subnet is valid

the transit subnet does not overlap another reserved range

the external connection belongs to the intended design

the current account has provider-level permissions

Connectivity Profile Creation Fails

Validate that:

the transit gateway is realized

the external IP block exists

the private TGW block exists

the edge cluster exists

the edge cluster supports the requested service path

the environment supports the selected centralized north-south design

EdgeCluster and ServiceCluster are not supplied together

Enabling north-south services with an edge cluster is a centralized-services pattern. Confirm that it matches the deployed VCF architecture before running the script.

Subnet Creation Fails

Check that each private subnet:

falls within the VPC private CIDR

does not overlap another subnet

uses a supported access mode

uses a valid DHCP mode

has enough available address space

can be realized by the selected connectivity profile

If adapting the example to create a public or private-TGW subnet, confirm that the correct provider IP block is associated with the connectivity profile and has sufficient free capacity.

External IP Assignment Fails

Check all of the following:

the requested IP is inside the associated external IP block

the IP falls within the configured allocation range

the IP is not reserved

the IP is not already assigned

the VM adapter is attached to the intended VPC subnet

the connectivity profile has north-south services enabled

only one of ExternalIp or AutoAssignExternalIp is used

the external address block is routed and operational upstream

To remove an existing assignment during controlled reconciliation, use UnassignExternalIp before requesting another address.

Get-VpcNatRule Returns Rules but Traffic Still Fails

NAT object presence does not prove packet delivery.

Validate:

guest IP configuration

guest default gateway

guest firewall

upstream routing

external VLAN reachability

gateway firewall policy

distributed firewall policy

physical firewall policy

return-path routing

source and destination port expectations

whether the application is actually listening

Generate test traffic, then inspect NAT statistics where supported.

Get-VpcNatRule Returns No Rules

Check that:

the VPC uses the expected connectivity profile

default outbound SNAT is enabled

the VM adapter is connected to the VPC subnet

an external IP was actually assigned

the requested address allocation completed successfully

the networking objects have finished realizing

Do not assume that an empty result means a missing PowerCLI module. It can also mean that no NAT state has been created for the VPC.

You Need a Custom NAT Rule

The documented high-level VPC cmdlet index exposes Get-VpcNatRule and Get-VpcNatRuleStatistics, but not a high-level New-VpcNatRule cmdlet.

Use connectivity-profile default SNAT and network-adapter external-IP assignment for the supported workflows shown here.

For a custom NAT rule, validate and use the relevant VCF 9.1 API or generated PowerCLI SDK binding rather than fabricating a high-level cmdlet.

Rollback Cannot Remove a Subnet or Provider Object

Treat the dependency error as a reason to stop.

Inventory:

attached VMs

external-IP assignments

connected VPCs

connectivity profiles

connectivity policies

shared IP pools

transit-gateway consumers

external-connection consumers

Never add wildcard removal merely to make the rollback script appear successful.

Production Improvements Beyond the Example

The single script is useful for learning and lab validation, but production automation should separate responsibilities.

Split Provider and Application Pipelines

The network-platform pipeline should own:

external connections

transit gateways

spans

edge-backed connectivity profiles

enterprise IP blocks

upstream routing coordination

Application pipelines should normally consume approved profiles and create:

VPCs

application subnets

workload attachments

approved external-IP assignments

This split reduces privilege, clarifies rollback, and allows provider objects to be lifecycle-managed independently of application releases.

Persist Desired State and Object IDs

Names are readable, but IDs are safer for long-term reconciliation.

Export a deployment manifest containing:

object names

object IDs

input CIDRs

allocated subnet ranges

external-IP assignments

connected VM adapters

module versions

execution timestamps

pipeline run identifiers

change-ticket identifiers

Store the manifest with the change record or pipeline artifact.

Add Preflight Address Validation

Before creating anything, validate:

CIDR overlap against existing VPCs

CIDR overlap against provider pools

requested external-IP membership

requested external-IP availability

reserved-address exclusions

transit-subnet uniqueness

upstream route ownership

IPAM approval

DNS requirements

The cmdlets can reject invalid platform state, but they cannot enforce every enterprise address-management rule.

Use Non-Interactive Authentication

Get-Credential is appropriate for an operator-run tutorial.

A production pipeline should use:

an approved secret store

a supported OAuth workflow

workload identity where available

short-lived tokens

scoped service identities

auditable credential rotation

Do not embed usernames, passwords, refresh tokens, or API tokens directly in the script.

Add WhatIf and Approval Boundaries

Where the cmdlet supports WhatIf, use it during planning and change review.

For cmdlets without a useful WhatIf path, add your own preview stage that prints:

objects that will be created

objects that will be reused

objects that differ from desired state

workloads that will be moved

external IPs that will be allocated

objects that rollback would remove

The preview should be generated before any state-changing command runs.

Create Evidence for Every Change

Capture before-and-after output from:

Get-VpcIpBlock

Get-VpcExternalConnection

Get-VpcTransitGateway

Get-VpcConnectivityProfile

Get-Vpc

Get-VpcSubnet

Get-VpcSubnetStatus

Get-VpcNatRule

Get-VpcNatRuleStatistics

Get-NetworkAdapter

Export the evidence as JSON so operators can compare desired state with realized state and preserve an audit trail.

Separate Control-Plane and Data-Plane Validation

A complete deployment has two validation gates.

Do not treat a successful control-plane deployment as proof that application traffic works.

The final acceptance gate should require both platform evidence and packet-flow evidence.

Conclusion

VCF 9.1 makes VPC networking a serious PowerCLI automation target rather than a small extension to VM provisioning.

The expanded VPC module can build the provider connectivity chain, allocate application networking, attach workloads, enable default outbound SNAT, and assign external IPs without leaving the PowerShell workflow.

The key is to automate the platform model accurately.

Default SNAT belongs on the connectivity profile. Workload publishing is requested through the VM network adapter. NAT state is validated with Get-VpcNatRule. Provider objects and application objects should have separate owners and separate rollback policies.

The end-to-end script in this article is a strong lab and implementation starting point, but the production pattern is modular:

establish a governed provider baseline once

let application pipelines consume it repeatedly

validate both control-plane state and packet flow

preserve evidence

remove only the objects the application pipeline truly owns

That approach turns PowerCLI from a collection of provisioning commands into a repeatable VCF networking operating model.

External References

VMware Cloud Foundation Blog: Programmable Infrastructure with VCF 9.1Canonical URL: https://blogs.vmware.com/cloud-foundation/2026/05/25/unlocking-the-full-potential-of-programmable-infrastructure-with-vmware-cloud-foundation-9-1-new-features-and-capabilities/

Broadcom Knowledge Base: VMware.VimAutomation.Vpc module does not autoload in VCF PowerCLICanonical URL: https://knowledge.broadcom.com/external/article/412787/vmwarevimautomationvpc-module-does-not-a.html

Broadcom Developer: New-VpcIpBlock Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpcipblock

Broadcom Developer: New-VpcExternalConnection Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpcexternalconnection

Broadcom Developer: New-VpcTransitGateway Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpctransitgateway

Broadcom Developer: New-VpcConnectivityProfile Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpcconnectivityprofile

Broadcom Developer: New-Vpc Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpc

Broadcom Developer: New-VpcSubnet Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/new-vpcsubnet

Broadcom Developer: Set-NetworkAdapter Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.core/commands/set-networkadapter

Broadcom Developer: Get-VpcNatRule Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/get-vpcnatrule

Broadcom Developer: Get-VpcSubnetStatus Command | Vmware PowerCLI ReferenceCanonical URL: https://developer.broadcom.com/powercli/latest/vmware.vimautomation.vpc/commands/get-vpcsubnetstatus

VMware Cloud Foundation Blog: Virtual Private Clouds (VPCs) in vCenterCanonical URL: https://blogs.vmware.com/cloud-foundation/2025/06/25/virtual-private-clouds-vpcs-in-vcenter/

VCF 9.1 VPC Networking: Distributed vs. Centralized Transit Gateway Designs
TL;DR VCF 9.1 supports two distinct approaches for connecting Virtual Private Clouds to the physical data center network. A Distributed Transit Gateway…

Next PostVCF 5.2.x to 9.1 Upgrade Runbook: Exact Sequence, Dependencies, Downtime, and ValidationTL;DR A VCF 5.2.x to 9.1 upgrade is not a single SDDC Manager update followed by routine infrastructure patching. It is a dependency-controlled platform transition that begins with the Operations…

The post Automating VCF 9.1 VPC Networking with PowerCLI: IP Blocks, Subnets, NAT, and External IPs appeared first on Digital Thought Disruption.
